Two Technologies That Change the Economics
Dust collection for paper, tissue and hygiene production starts where the dust is made, not where it lands. ERS captures fine airborne fiber, lightweight dust and trim particulate at the die cutter, the converting line and the packaging station, and engineers the ducting, the pressure control and the filtration behind it as one system.
The Balancing Fan
Dust enters through ERS-engineered hoods and ductwork, and the Balancing Fan holds the system steady behind it. It neutralizes pressure fluctuations and keeps airflow consistent across the whole installation, which is what prevents suction loss when several stations call for air at once. It also means the system draws only the horsepower the duty needs, instead of running at peak all shift because that is how it was sized.
Most plants discover this the expensive way: the system works on commissioning day with two machines running, then falls over when the third line starts.
The CCM® OCT Filter
Dust is pneumatically conveyed to the CCM® OCT filter, where rotating and oscillating suction nozzles clean the media every two to three minutes while the plant keeps running. That continuous cleaning is what holds pressure drop low, filtration efficiency high and filter life long, and it needs no compressed air to do it.
Mechanically it is simple on purpose. One gear motor sits outside the filter, out of the dust, and turns the central shaft and the boom. The nozzle traverse takes its motion from that rotation, so nothing electrical moves inside the drum. Scrapers turn with the shaft and wipe dust off the rings back onto the media. A media change is tool-free at roughly four to six minutes per panel.
What Happens to the Collected Dust
Collected dust is discharged into a high-efficiency cyclone and compacted into dust pucks, which handle and dispose of far more easily than loose fiber and can go into the waste stream without a second handling step. Where the material is worth recovering, it feeds the same collection route as the trim.
What Uncollected Dust Costs
Dust that is not collected gets paid for twice. The first bill is cleaning labor, filter changes on unrelated equipment and the slow loss of visibility across the floor. The second is the one nobody budgets for: fiber working into bearings and drives, product rejected for contamination, and a line stopped for a clean-down that was never on the maintenance schedule. A system sized properly at the outset is almost always cheaper than the housekeeping it replaces.
Trim, Separation and Baling
Where the plant also produces trim, the material comes out of the airstream before the baler. The Low Profile Separator does that in a fraction of the height a conventional cyclone needs, and where headroom allows ERS builds conventional cyclone separators into the same position. ERS supplies and integrates the industrial balers downstream as part of the same installation. The complete chain is set out under trim removal and vacuum transfer air dust collection.
The Air Side of a Transfer System
Where material is moved pneumatically, the air doing the moving has to be cleaned as well. That is vacuum transfer air dust collection, sized for the whole plant running at once. Facilities running several lines are better served by turnkey waste conveyance and dust collection systems that bring every station into one engineered waste stream.
Industries Served
ERS dust collection supports facial tissue converting, diaper and hygiene product manufacturing, corrugated board production, paper container converting and packaging lines. The duty changes with each one: tissue converting throws light fiber in bursts at the log saw, corrugated box plants produce heavy continuous trim, folding carton converting sits between the two, and label converting is different again. The same engineering also serves paperboard production, paper converting, commercial printing, flexible packaging and paper mills.
The converting-specific air side is covered under dust collection systems for paper converting, and the wider equipment range on the paper converting systems page.
Designed to the Plant, Not to a Catalog
Each system is custom-designed around the airflow demand, the substrate types and the production speeds of the lines actually installed. Systems are engineered to support compliance with OSHA, NFPA and workplace safety requirements, worked through with the plant and its insurer site by site. What the plant gets day to day is clean air, less maintenance, better visibility on the floor and stable, energy-efficient airflow control.
Service and Spare Parts
A filter is worth what it does in year five. ERS keeps a stocked warehouse and supports every installation it builds, from commissioning through to spare parts and service. Filter media, wear parts and fan components are available without a lead time measured in months.
Next Steps for Your Dust Collection Project
If you are evaluating dust collection for paper, tissue and hygiene production or planning an upgrade to an existing system, send the details through the contact form. ERS will review the airflow demand, the substrates and the line speeds and come back with a system configuration that fits.
